Place of Origin:
China
Brand Name:
QuanJiang
Certification:
SGS
Model Number:
0.20*895*1038
Contact Us
TINPLATE
Tinplate is a thin steel coated with tin. Tinplate is characterized by its beautiful metallic luster
as well as excellent properties in corrosion resistance, solderability and weldability.
TIN FREE STEEL( TFS)
TFS is electrolytic chromium coated steel, which has a superior paintability and paint adhesion.
Since TFS has an excellent sulfide stain resistance, it can be applied to food usage with
inside coating.
| Applications of Tinplate and TFS |
| TFS are most frequently used for can tops, screw and lug caps, snap and press-on closures and shallow-drawn food cans. |
| ETP is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP. |
Electrolytic tinplate Paramenters
| PRODUCT | Prime tinplate |
| STANDARD | BS EN 10202, DIN EN 10203, GB/T2520 , JIS G3303 |
| MATERIAL | MR SPCC |
| Grade | Prime |
| Annealing | BA,CA |
| THICKNESS | 0.20mm, 0.21mm, 0.23mm, 0.35mm customized |
| WIDTH | 895mm, 894mm or customized |
| TEMPER | T2, T2.5, T3, T3.5, T4,T5 ,DR7,DR7M,DR8 |
| COATING: | 2.8g/2.8g, 5.6g/5.6g, 2.8/5.6,2.0/2.0 gr/m² or according to customer's requirement |
| FINISHS: . | Bright,Silver,Stone, Matte |
|
PACKINGS: |
export packing. Or according to customer's requirements. |
| MOQ | 25 tons |
| DELIVERY | 15-30 days after payment |
Application:
Tinplate is widely used for the packaging of products. Such as food cans,
beverage cans, pet cans, closures,general line cans and so on.
| Classification | Main Applications | |
| Food Cans | Cans for preserved food | Preserved fishery and agricultural products, etc. |
| Cans for beverages | Juice, carbonated soft drinks, other beverages, etc. | |
| General Cans | 4L Cans | Automobile oil, mechanical oil, etc. |
| 18L Cans | Industrial containers for paint and oils | |
| Pail Cans | Industrial containers for paint and oils | |
| Aerosol Cans | Cosmetics, butane gas, pesticide, etc. | |
| Crown | Crown Caps | Liquor, soft drink bottle caps |
| Others | Electronic Components | Electronic items such as TV, tuner cases, etc. |
| Electronic Jar | Electronic items such as electric cookers, etc. | |
| Others | Other shell of batteries, toys, stationeries, etc. | |
