Place of Origin:
China
Brand Name:
QuanJiang
Certification:
SGS
Model Number:
MR 0.23mm rust resistance SPTE
Contact Us
Prime Electrolytic Tin Plate for Canning with Excellent Alkali and Rust Resistance
| Material | MR PRIME TINPLATE / TIN FREE STEEL |
| Thickness | 0.14 to 0.45mm |
| Width | 660 to 1020 mm |
| Length | 600 to 1200 mm or Coils |
| Tin coating | 2.8g/2.8g/m², 5.6g/5.6g/m², 2.8/5.6g/m²,2.0/2.0g/m² or according to customer's requirement |
| Temper | T2, T2.5, T3, T3.5, T4,T5 ,DR7,DR7M,DR8 , DR9 |
| Annealing | CA(Continuous annealing) and BA(Batch annealing) |
| Surface | Bright/Stone/Silver finish with passivation treatment; DOS oil |
| MOQ | 25 tons or one container |
| Payment | T/T |
| Reference standard | GB/T 2520-2008, JIS G3303-2008 ,DIN EN 10203-1991, ASTM A623M-2011 |
| Applications: | Widely used for metal packaging industry. Such as making cans for food, tea, oil, paints, chemicals, aerosol, gifts, printing |
Product Show
Application:
Tinplate is widely used for the packaging of products. Such as food cans,
beverage cans, pet cans, closures,general line cans and so on.
| Classification | Main Applications | |
| Food Cans | Cans for preserved food | Preserved fishery and agricultural products, etc. |
| Cans for beverages | Juice, carbonated soft drinks, other beverages, etc. | |
| General Cans | 4L Cans | Automobile oil, mechanical oil, etc. |
| 18L Cans | Industrial containers for paint and oils | |
| Pail Cans | Industrial containers for paint and oils | |
| Aerosol Cans | Cosmetics, butane gas, pesticide, etc. | |
| Crown | Crown Caps | Liquor, soft drink bottle caps |
| Others | Electronic Components | Electronic items such as TV, tuner cases, etc. |
| Electronic Jar | Electronic items such as electric cookers, etc. | |
| Others | Other shell of batteries, toys, stationeries, etc. | |
Production Process
PARTNER
CERTIFICATE
Information Required with orders and inquirys
Orders and inquiried shall be accompanied by the following information.
1. products name and grade
2.coaing and mass( for Tinplate only),temper grade,finish, and products size.
3.rolling direction
4.quantity
5.application and delivery date
6.number of sheets per packaging( for cut to length products)
7.inside diameter amd maximum acceptable unit coil weight (for coils products).
8.film type,color, contents,and other details of use and environment.
9.other special requirements,if any.
